Features

• 800x480 Color TFT touch screen and easy to use with function key control.

• High resolution "8 dot / mm" thermal printing system and recording frequency up to 150Hz.

• Anti-defibrillation feature.

• 6-channel simultaneous 12-lead ECG data acquisition.

• Complete digital filters against deviations.

• 110mm thermal paper.

• "Lead off" and "Lack of Paper" warning feature.

• Automatic measurement and interpretation.

• In case of optimum DC, it can print continuously up to 90 minutes.

• Measurement parameters: HR, P-R interval, P Duration, QRS Duration, T Duration, Q-T interval, Q-Tc, P Axis, QRS Axis, T Axis, R(V5), S(V1), R(V5)+S(V1).
